Hex Bolt & Nut Set (Half Thread)

$2.00
(No reviews yet) Write a Review
Minimum Purchase:
4 units
  • Material Grade : Stainless steel SS316
  • Dimensional standard : ASME B18.2.1



Dimension

1/2" to 36"Stub flange specification.



Dimension Table

Bolt & Nut Specification
Flange & Manway Specification
Bolt
Size
(inch)
Length
(inch)
Half
Thread
Full
Thread
Nominal
Diameter
(inch)
Pressure
Rating
(psi)
Bolt Hole
Diameter
(inch)
Amount of
Bolt Holes
Flange
Thickness
(inch)
Remarks
5/8
2 3/4
V

2
150
3/4
4
11/16
Flange
5/8
3
V
V
3
150
3/4
4
13/16
5/8
3 1/4
V

4
150
3/4
8
15/16
3/4
2 3/4
V

6
50
7/8
8
5/8
3/4
3 1/2
V
V
150
7/8
8
1 1/16
3/4
3
V

8
50
7/8
8
3/4
3/4
4
V
V
150
7/8
8
1 1/4
7/8
3 1/4
V

10
50
1
12
7/8
7/8
4 1/2
V

150
1
12
1 7/16
7/8
3 1/2
V

12
50
1
12
1
7/8
5
V

150
1
12
1 3/4
1
4
V

14
50
1 1/8
12
1 1/16
1
5 3/4
V

150
1 1/8
12
1 7/8
1
4 1/4
V

16
50
1 1/8
16
1 3/16
1
6
V

150
1 1/8
16
2
1 1/8
4 1/2
V

18
50
1 1/4
16
1 1/4
1 1/8
6 1/2
V

150
1 1/4
16
2 1/4
1 1/8
4 3/4
V

20
50
1 1/4
20
1 5/16
1 1/8
7
V

150
1 1/4
20
2 7/16
1 1/4
5 1/4
V

24
50
1 3/8
20
1 1/2
1 1/4
8
V

150
1 3/8
20
2 13/16
5/8
3
V
V
20
10PSI
3/4
20
3/4
Manway
3/8
1 3/4
V
V
24
ATM
1/2
20
3/8
5/8
3
V
V
10PSI
3/4
20
3/4
5/8
4
V
V
25PSI
3/4
20
1 1/4
Weight:
0.50 LBS
