FRP Stub Flanges (ANSI-OD)

$41.29
(No reviews yet) Write a Review
  • Precise control of the outside diameter and uniform external surface ensure ease of connecting & installation.
  • Manufactured with reference to PS 15-69 & ASTM D5421.
  • C-veil + 2 Mats 100mil resin rich corrosion resistant liner.
  • Hand laid, integral type construction, woven roving used continuously from flange face to hub for 3 inches size and larger.
  • Bolt holes of drilled flanges are coated with resin.
  • Standard inventory available in basic Vinyl Ester Resin and Fire Retardant Resin. Supply using other resin systems possible.
  • MEKPO cure system.



Weight:
3.25 LBS
