FRP U-Vent

$34.00
(No reviews yet) Write a Review



  • Manufactured to conform to PS15-69
  • C-veil and Nexus + 2 Mats 100mil resin rich corrosion liner
  • Hand laid one piece construceion; 90o Elbow radius equals to 1.5 times of the ID
  • Standard inventory available in Vinyl Ester Resin, Derakane Momentum 411-350, 470-300, 510C-350 & Hetron 922. To supply equivalent resin system can be available upon request
  • MEKP (C + N Liner) & BPO (C + 2N Liner) cure systems

1/2" to 36"Stub flange specification.

Inside
Diameter
( ID )
Pressure
Rating
O.D. of
Pipe
( OD )
Wall
Thickness
( t )
Overall
Height
( OH )
Sweep
Diameter
( SD )
Pipe
Length
( PL )
Grinding
Length
( GL )
inch
psi
inch
inch
inch
inch
inch
inch
2
25
2- 3/8
3/16
14- 3/16
8- 3/8
10
3
3
25
3- 3/8
3/16
16- 3/16
12- 3/8
10
3
4
25
4- 3/8
3/16
18- 3/16
16- 3/8
10
3
6
25
6- 3/8
3/16
22- 3/16
24- 3/8
10
4
8
25
8- 3/8
3/16
26- 3/16
32- 3/8
10
4
10
25
10- 3/8
3/16
30- 3/16
40- 3/8
10
4
12
25
12- 3/8
3/16
34- 3/16
48- 3/8
10
4
14
25
14- 1/2
1/4
40- 1/4
56- 1/2
12
5
16
25
16- 1/2
1/4
44- 1/4
64- 1/2
12
5








Weight:
1.00 LBS
